Creating a new site

Create a new site by click "Create New" on the right side of the page.

A new dialog is opened, to fill in the necessary information for a site. It contains four separate tabs; General, parameters, machines and zones.

General tab

General tab contains total of five fields of informations, that can be filled, from these there are three mandatory (*) fields:

• Name*

  • Site name

• Longitude*

  • Estimated longitude of the project

• Latitude*

  • Estimated latitude of the project

• Group

  • Allows you to assign users to a single site

• Description

  • Free text field to give more information about the site

Parameters tab

Parameters tab contains total of five fields of information, that can be filled. There are not mandatory but it is highly recommended to fill these to obtain accurate feedback about the production.

Machines tab

Machines tab is something that cannot be filled when creating the site. The site must be established and after that, machines can be added to it. This workflow is covered in the next page, Editing an existing site.

Zones tab

Zones tab is something that is edited when creating the site. Zones must be added from zone section in the Asset Management section. This workflow is covered in the next page, Editing an existing site.

Next step

After all the general information is filled, click Submit (or create in other words) the site. If something went wrong, the site can be edited or deleted later, but it is also possible to cancel the creation at this point.

After clicking Submit, the new site appears on the list and it can be edited or deleted.
